| CPU+PCH |
Intel® Alder lake-S 12th-Gen Core™ i9/i7/i5/i3/Pentium/Celeron LGA1700 CPU，Intel® Q670 PCH |
| Memory |
2*262-Pin SODIMM, dual channel DDR5 4800MHz, up to 64GB |
| Expansion |
1*Full size Mini PCIe (PCIeX1+USB signal) with SIM slot, for 4G LTE modem or PCIe signal I/O module
1*Full size Mini PCIe (PCIeX1 or SATA signal), automatic detection of SATA signal and PCIe signal
1*M.2 B-Key 3052 (PCIeX1+USB signal) with a SIM slot, support 5G NR modem
1*M.2 2280 M-Key (Gen4, X4 signal, from PCH), support NVME high-speed SSD or PCIe signal module
2*PCIe X16 (Gen5, X8 signal, from CPU), support two highest power consumption 450W GPU card or AI acceleration card (the length of the card must be less than 300mm)
2*PCIe X16 (one is Gen4 and the other is Gen3, X4 signal, from PCH), support 2*75W consumption AI acceleration card (the length of the card must be less than 300mm) |
| Graphics |
Intel® UHD Graphics, Supports DirectX 12, OpenGL 4.5，OpenCL 3.0, DP max res. 7680*4320@60Hz,HDMI max res. 4096*2160@60Hz, VGA max res. 1920*1200@60Hz, support three independent displays |
| Audio |
Realtek ALC897 controller, Line out and MIC high fidelity audio, support 5.1 channel |
| LAN |
2*Intel I226V 2.5G Gig. Ethernet, PCIeX1 full bandwidth, 10M/100M/1000M/2.5Gbps;
1*Intel I219LM Gig. Ethernet, 10/100/1000Mbps, support iAMT12.0 and vPro (only Core I5/I7/I9 CPU) |
| Storge |
2*2.5 “SATA3 easy-plug SATA bays, larger capacity thickness15mm HDD, support Raid0/1;
1*M.2 2280 M-key(Gen4, PCIeX4 signal), support NVMe ultra-high speed storage;
1*Full size Mini PCIe (PCIeX1 or SATA signal) automatically detects mSATA |
| DIO |
Optional 16bit DIO, TTL signal, programmable input/output |
| I/O Interface |
3*RJ45 Gig-LAN; 4*USB3.2(gen2.0 10Gbps, Type A,); 2*USB3.2(gen1.0 5Gbps, Type A); 2*RS232/422/485(via BIOS, DB9 male);
1*VGA+1*DP+1*HDMI; 1*Line out+1*Mic (3.5mm phone jack)；
2*USB2.0(pin header inside); 16bit DIO (2*10pin header inside); 1*F_Audio (pin header inside) |
| I-port |
Support 16bit DIO pin header lead wire , USB2.0 or Mini PCIe and other expansion interfaces lead wire |
| LED |
1*Power LED(on power button), 1*HDD LED, 3*CPU temp LED（Red is warning , Yellow is high,
Green is normal） |
| Control SW |
1*Power button w/LED, AT/ATX dip, Clear Cmos dip |
| Power Supply |
DC IN 12V, 5-pin 7.62mm Term., with short circuit(SCP) and overcurrent(OCP) protection, maximum output power 1000W
TDP: TBD |
| Watchdog Timer |
Watchdog timeout programmable via software 1 to 255 second |
| OS Support |
Windows 11，Windows 10 IoT Enterprise 2021 LTSC, Ubuntu, SuSe, Red Hat Enterprise, Wind River Linux, Wind River VxWorks 7 |
| Structure |
SGCC frame, Aluminum-magnesium alloy chassis, temperature control by PWM fan |
| Color |
Granite gray + Black |
| Mounting |
Desktop Mounting, with anti-vibration rubber pads |
| Dimension |
(W*H*D)：245*376.8*254.8 mm |
| Net weight |
TBD |
Operating
temperature |
-20℃～60℃, airflow |
| Storage Temperature |
-40°C~85°C |
| Storage Humidity |
10~95%@40°C, Non-condensing |
| Vibration |
5grms/5~500Hz/random/in working (SSD); 1grms/5~500Hz/random/in working (HDD) |
| Shock |
50g peak acceleration(11ms duration)(SSD); 20g peak acceleration(11ms duration)(HDD） |
| Certification/EMC |
CE/FCC Class A |
