RCO-6000-CFL-4NH AIエッジコンピューティング

Intel® CFL-R Sプロセッサ搭載、ハイパフォーマンスと豊富なストレージ拡張性を両立させた頑丈なエッジコンピューティング

製品特徴:

  • LGA 1151 socket for 8th/9th Gen. Intel® CFL-R S Processor Pentium® / Celeron® Desktop Processor
  • Intel® Q370 chipset
  • NVIDIA GeForce® RTX 2060 Super Graphics engine based on NVIDIA TurningTM GPU architecture
  • 2x 260-pin DDR4 SODIMM. Max. up to 64GB
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x Intel® GbE supporting Wake-on-LAN and PXE
  • 2x Removable 2 Bay NVMe SSD Module with Hardware RAID 0, 1, 5, 6, 10 support (Support H=15mm)
  • 4x 2.5” SATA HDD Bay and 2x mSATA with RAID 0, 1, 5, 10 support
  • 1x M.2 (M Key, NVMe PCIe x4, 2280); 1x M.2 (E Key, PCIe x2, USB 2.0, 2230, Support CNVi)
  • 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature (-25°C to 60°C)
  • Power ignition management

製品概要・特徴

ハイパフォーマンスと豊富なストレージ性を両立させた頑丈なエッジコンピューティング
インテル第8/9世代プロセッサーによる優れたAIエッジコンピューティング、

リアルタイムのデータ分析、豊富なストレージ性能を実現した製品です。

SSD/HDD 2x Internal 2.5″ SATA HDD Bay (support H=9.5mm)
2x Removable 2.5″ SATA HDD Bay
(support H=7mm, hot-swappable) Support RAID 0, 1, 5, 10
NVMe 2x Removable 2 Bay NVMe SSD Module with Hardware
RAID 0, 1, 5, 6, 10 support (Support H=15mm)
mSATA 1x mSATA (Shared by 1x Mini PCI Express)
M.2 1x M.2 (M Key, NVMe PCIe x4, 2280)
1x M.2 (E Key, PCIe x2, USB 2.0, 2230, Support CNVi)
SIM Socket 2x External SIM socket



【簡素化したメンテナンス
正面からメンテナンスが容易な冷却ファンデザインで、
外部より簡単に取り外すことができ、過酷な環境の要求に応じて頻繁に交換することができます。



スペック情報

Specification
System
Processor Support 8th/9th Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W TDP)
Intel® Core™ i7-9700E, 8 Cores, 12MB cache, up to 4.4 GHz (24V)
Intel® Core™ i5-9500E, 6 Cores, 9MB Cache, up to 4.2 GHz (24V)
Intel® Core™ i3-9100E, 4 Core, 6MB Cache, 3.7 GHz (24V)
Intel® Core™ i7-9700TE, 8 Cores, 12MB cache, up to 3.8 GHz
Intel® Core™ i5-9500TE, 6 Cores, 9MB Cache, up to 3.6 GHz
Intel® Core™ i3-9100TE, 4 Core, 6MB Cache, 3.2 GHz
Intel® Core™ i7-8700T, 6 Cores, 12MB cache, up to 4.0 GHz
Intel® Core™ i5-8500T, 6 Cores, 9MB Cache, up to 3.5 GHz
Intel® Core™ i3-8100T, 4 Cores, 6MB Cache, 3.1 GHz
Intel® Pentium® G5400T, 2 Cores, 4MB Cache, up to 3.1 GHz
Intel® Celeron® G4900T, 2 Cores, 2MB Cache, up to 2.9 GHz
System Chipset Intel® Q370 Express Chipset
LAN Chipset GbE1: Intel® I219LM (Support Wake-on-LAN and PXE)
GbE2: Intel® I210-AT (Support Wake-on-LAN and PXE)
Audio Codec Realtek ALC888S
System Memory 2x 260-Pin DDR4 2400/2666MHz SODIMM.
Max. up to 64GB (Un-buffered and Non-ECC)
BIOS AMI 256Mbit SPI BIOS
Watchdog Software Programmable Supports 1~255 sec. System Reset
TPM TPM 2.0
Display
Graphics Intel® UHD Graphics 610/630
DVI 1x DVI-I, support resolution 1920 x 1200
DisplayPort 2x DisplayPort, support resolution 4096 x 2304
Multiple Display 3 Display interfaces
Storage
SSD/HDD 2x Internal 2.5″ SATA HDD Bay (support H=9.5mm)
2x Removable 2.5″ SATA HDD Bay
(support H=7mm, hot-swappable) Support RAID 0, 1, 5, 10
NVMe 2x Removable 2 Bay NVMe SSD Module with Hardware
RAID 0, 1, 5, 6, 10 support (Support H=15mm)
mSATA 1x mSATA (Shared by 1x Mini PCI Express)
M.2 1x M.2 (M Key, NVMe PCIe x4, 2280)
1x M.2 (E Key, PCIe x2, USB 2.0, 2230, Support CNVi)
SIM Socket 2x External SIM socket
Expansion
Mini PCI Express 2x Full-size Mini PCIe (1x shared by 1x mSATA)
4-Port GbE (Optional) 4-port GbE module with Intel® I350-AT4 Chipset,
RJ-45 or M12 connector (PoE optional)
Occupied one Universal I/O Slot
2-Port GbE (Optional) 2-Port RJ45 10GbE with Intel X710-AT2 Chipset
Occupied one Universal I/O Slot
4-Port USB (Optional) 4-Port USB with Renesas uPD720201K8 host controller
Occupied one Universal I/O Slot
5G (Optional) 1x M.2 for 5G (B Key, PCIe x4, USB 3.0, 3042/3052)
Including 2x SIM socket, 1x SIM switch
Occupied one Universal I/O Slot
Operating System
Windows Windows 10
Linux Linux kernel 5.X
I/O
COM 4x RS-232/422/485
2x RS-232/422/485 (internal)
USB 4x USB 3.2 Gen 2 (10 Gbps)
5x USB 3.2 Gen 1 (5 Gbps)
1x USB 3.2 Gen 1 header (5 Gbps, internal)
LAN 2x RJ45
Audio 1x Mic-in, 1x Line-out
DIO 8 in / 8 out (Isolated)
Universal I/O Bracket 1x Universal I/O Bracket (By mini PCIe interface)
Others 5x WiFi Antenna Holes
1x Power Switch, 1x AT/ATX Switch, 1x Remote Power On/Off
1x PC/Car Mode Switch, 1x Delay Time Switch
1x Removable CMOS Battery
Power
Power Mode AT, ATX
Power Supply Voltage 9~48VDC
Power Ignition Sensing Power Ignition Management
Power Connector 3-pin Terminal Block, 4-pin Terminal Block for Storage
(12V requires 4-pin terminal block)
Power Adaptor Optional AC/DC 24V/9.2A, 220W
Optional AC/DC 24V/11.27A, 280W
Power Protection OVP (Over Voltage Protection);
OCP (Over Current Protection)
Reverse Protection
Environment
Operating Temp. -25°C to 60°C (35W /65W CPU)
Storage Temp. -30°C to 85°C
Relative Humidity 10% to 95% (non-condensing)
Vibration With SSD: 3 Grms, 5 – 500 Hz, 0.5 hr/axis
With HDD: 1 Grms, 5 – 500 Hz, 0.5 hr/axis
Shock With SSD: 20G, half sine, 11ms
Standards / Certification CE, FCC Class A, E-Mark,
EMC Conformity with EN 50155, EN 50121-3-2
Physical
Construction Extruded Aluminum with Heavy Duty Metal
Dimension 261 (D) x 240 (W) x 148 (H)
Weight 10.2 kg
Mounting Wall Mounting
