製品概要・特徴
NXP i.MX8M Plus (Quad core)搭載・コンパクトエッジゲートウェイ
NEX-8MP + NEX-001
Edge Gateway Box PC
with NXP® i.MX8M Plus solution
NXP i.MX8M Plus (Quad core)搭載・コンパクトエッジゲートウェイ
主な機能：
- NXP i.MX8M Plus (Quad core) ARM Cortex-A53
processor up to 1.8 GHz (NEX-8MP) - LPDDR4, 6GB (NEX-8MP)
- 32GB eMMC 5.1 (NEX-8MP),
expandable to 256GB - HDMI ; 2 x GbE ; 2 x USB 3.0 / 2.0
- 1 x Micro SD, 1 x RS232, 1 x RS485
- 2 x CANBus
スペック情報
| MODEL | NEX-8MP + NEX-001 | |
|---|---|---|
| Dimension(WxDxH) | 71.4W x 71.4D x 29.5H mm | |
| Weight(Incl.M/B) | 258g | |
| CPU | NXP i.MX8M Plus (Quad core) ARM Cortex-A53 processor up to 1.8 GHz (NEX-8MP) | |
| GPU | Vivante GC700UL GPU (NEX-8MP) | |
| Memory | LPDDR4, 6GB (NEX-8MP) | |
| Storage | 32GB eMMC 5.1 (NEX-8MP) , expandable to 256GB 1 x Micro SD |
|
| Expansion slot
I/O ports |
Network | 2 x GbE |
| USB | 2 x USB 3.0 / 2.0 | |
| Serial ports | 1 x RS232 ; 1 x 485 , 2 x CANBus | |
| Display | 1 x HDMI | |
| Power | DC input : +5V | |
| Operating Temp. (100 % CPU usage) |
-20°C to +60°C | |
| Storage Temp. | -20°C to +70°C | |
| Relative Humidity | 95% @ 40°C, non-condensing | |
