| CHIPSET | NXP i.MX8M Plus+Kinara Ara-2 | ||||||||||
| MARKET AREA | Global | ||||||||||
| Core parameters | OS | Yocto(Linux) | |||||||||
| SoC | 4 x Cortex-A53, up to 1.8GHz&1 x Cortex-M7, up to 800MHz | ||||||||||
| GPU | GC7000UL with OpenCL and Vulkan support Supports OpenGL ES 1.1, 2.0, 3.0, OpenCL 1.2, Vulkan |
||||||||||
| NPU | iMX8M Plus | 2.3 TOPS Neural Network performanc | |||||||||
| Kinara Ara-2 | 40TOPS Neural Network performanc | ||||||||||
| TensorFlow,PyTorch,ONNX AI Model | |||||||||||
| Memory | iMX8M Plus | 4GB（1G-8G optional） | |||||||||
| Kinara Ara-2 | 16GB | ||||||||||
| Storage | 32GB eMMC5.1(8-128GB optional) | ||||||||||
| I/O interface | Network Interface | 2 x Giga Ethernet | |||||||||
| Wifi2.4G+5G +BT 5.0 | |||||||||||
| Video Interface | 1 x HDMI output 1 x LVDS Screen Connector 2x15P 1 x MIPI DSI connector for MIPI Panel 1 x MIPI CSI connector for MIPI Camera 4 lanes 1 x MIPI CSI connector for MIPI Camera 4 lanes |
||||||||||
| USB interface | 1 x USB 2.0 Type A 1 x USB 3.0 Type A 1 x USB Type C 2 x USB2.0 4P Header |
||||||||||
| PCIe interface | 1 x M.2 Key M for M.2 AI module（It cannot be used simultaneously with onboard AI chips） |
||||||||||
| SD Card | 1 x Micro SD card slot | ||||||||||
| SIM Card | 1 x Micro SIM card slot | ||||||||||
| Extended interface | 1 x Mini PCIe for 4G | ||||||||||
| Communication interface | 2 x RS232/RS485 1 x CAN 2 x DI 2 x DO |
||||||||||
| Other interfaces | 1 x A53 Core Debug connector (UART) 1 x I2C Touch Screen connector 1 x RTC-Battery 1 x Expended Connector 2x26P Header 1 x FAN 4P Header with FAN PWM 1 x LCD Backlight 6P Header 1 x LVDS Panel Power Switch 1 x System boot mode switch 1 x System upgrade key 1 x Reset Key 1 x DC Jack |
||||||||||
| Power supply input | DC 12V /3A | ||||||||||
| Size | 172*123.7*43.5mm | ||||||||||
| Weight | 1050g | ||||||||||
