| Technical Specifications — eBOX-3000H-S |
| Model Name |
eBOX-3000H-SE |
eBOX-3000H-SP |
| System |
| CPU |
Intel® 12/13/14th Generation Celeron/Pentium/Core™ series processor, TDP up to 65W |
| BIOS |
AMI UEFI 128Mbit |
| Chipset |
Intel H610 |
| Memory |
2 × 260-pin DDR4 3200MHz SO-DIMM slots, up to 64GB |
| Storage |
1 × M.2 2242/2280 Key-M slot SATA3.0 (up to 6Gb/s); 1 × SATA3.0 (up to 6Gb/s) |
| USB |
4 × USB3.0, 4 × USB2.0 |
| COM |
4 × RS-232 (COM1-4), 2 × RS-232/RS-485 (COM5-6) |
| Expansion Slots |
1 × PCIe x16; 1 × MINI PCIe (Wi-Fi/4G); 1 × M.2 Key-B (5G module expansion) |
2 × PCI; 1 × MINI PCIe (Wi-Fi/4G); 1 × M.2 Key-B (5G module expansion) |
| LAN |
2 × Intel GbE LAN |
| VGA |
Up to 1920 × 1200 @60Hz; supports asynchronous dual display |
| HDMI |
Up to 4096 × 2160 @30Hz; supports asynchronous dual display |
| DVI |
Up to 1920 × 1200 @60Hz; supports asynchronous dual display |
| Watchdog |
1~255 levels programmable setting |
| OS Support |
| OS |
Windows 10, Windows 11, Linux |
| Power |
| Input Voltage |
DC12-24V |
| Chassis |
| Dimensions (L×W×H) |
(L)242mm × (W)240mm × (H)117.73mm |
| Net Weight |
4.7kg |
| Environment |
| Operating Temperature |
-20°C ~ 60°C (Use SSD) |
| Storage Temperature |
-40°C ~ 80°C (Use SSD) |
| Relative Humidity |
5~95% RH @40°C, non-condensing |
| Vibration |
SSD applied: 1.5Grms, IEC 60068-2-64, random, 5~500Hz, 1 hr/axis |
| Shock |
SSD applied: 10G, IEC 60068-2-27, Half sine wave, lasting 11ms |
| EMC |
CE/FCC Class A |
