| Technical Specifications — NP-6133 Ultra 16I16O |
| Model Name |
NP-6133-16I16O-225H |
NP-6133-16I16O-255H |
| System |
| CPU |
Intel® Core™ Ultra 225H CPU, 14 cores / 14 threads, 1.3~4.9GHz, 18MB cache |
Intel® Core™ Ultra 255H CPU, 16 cores / 16 threads, 1.5~5.1GHz, 24MB cache |
| TDP |
28W |
| BIOS |
AMI UEFI BIOS |
| GPU |
Intel® Arc™ 130T GPU |
Intel® Arc™ 140T GPU |
| NPU |
Intel® AI Boost |
| Peak TOPS |
83 (GPU63+NPU13) |
96 (GPU74+NPU13) |
| Memory |
2 x SO-DIMM DDR5-5600MT/s (up to 96GB) |
| Storage |
1 x mSATA, SATA3.0 |
| USB |
4 x USB3.0
1 x USB2.0 Type-A on the board for USB dongle |
| COM |
1 x RS232/RS485 (COM1), maximum baud rate: 115.2kbit/s |
| Ethernet |
4 x Intel i210-AT GbE LAN controller
1 x Extended LAN |
| Remote |
1 x SW |
| DI |
16 x DI, NPN/PNP |
| DO |
16 x DO, NPN or PNP (select the mode by switch), Imax: 0.5A |
| VGA |
Support up to 1920 x 1080 @60Hz |
| HDMI |
Support up to 3840 x 2160 @60Hz |
| Expansion |
2 x Full-size PCIe Mini slot with SIM card holder, expansion WIFI/3G/4G/CAN modules |
| Watch Dog |
1~255 levels programmable |
| TPM |
dTPM: SLB9672XU2.0 |
| OS |
| Microsoft Windows |
Windows 10, Windows 11 |
| Linux |
Ubuntu, Debian |
| Power |
| Voltage Input |
DC12~24V ±10%, overcurrent, overvoltage and polarity inverse protection |
| Power Consumption |
Max. 90W |
| Chassis |
| Structure |
Aluminum-magnesium alloy BOX with fan embedded to assist cooling, Wall-mounted or DIN-Rail fixing style |
| Dimensions |
(L)200mm x (W)150.5mm x (H)74.6mm |
| Net Weight |
2.4Kg |
| Environment |
| Work Temperature |
-20ºC ~ 60ºC (-4ºF ~ 140ºF) with air flow (SSD) |
| Storage Temperature |
-40ºC ~ 80ºC (-40ºF ~ 176ºF) with air flow (SSD) |
| Relative Humidity |
95%@40ºC (Non-condensing) |
| Operating Vibration |
5~500Hz, 3Grms@with SSD and Wall-mounted, Follow IEC60068-2-64 |
| Operating Shock |
30G peak acceleration (11ms duration) with SSD and Wall-mounted, Follow IEC60068-2-27 |
| EMC |
CE EMC, Follow IEC / EN 61000-6-2, IEC / EN 61000-6-4, FCC Class A |
| Safety |
Follow IEC / EN 62368-1 |
